++++++++++++++++ 1912 ++++++++++++++++
1912-13 Delco 6-24 volt system care
1912-14 Delco 6-24 volt dual ignition system care
++++++++++++++++ 1913 ++++++++++++++++
1913 Hudson Salesman Book 'How to Sell the Hudson 37'
1913 Hudson Instruction Handbook
++++++++++++++++ 1914 ++++++++++++++++
1914-15 Hudson 6-54 Prices Specifications and Equipment
1914-16 Service Inspection Manual for Hudson Mechanics
++++++++++++++++ 1915 ++++++++++++++++
1915 Standard Delco Systems Care
1915 Delco Circuit and wiring Diagrams all car makes 1910 thru 1915
++++++++++++++++ 1916 ++++++++++++++++
1916 Delco Care of Standard Delco Systems having third brush regulations
1916 - 1918 Super Six Service Manual For Hudson Mechanics Models H J and M
1916 Hudson Super-Six Reference Book
++++++++++++++++ 1917 ++++++++++++++++
Delco Circuit Diagrams of the 1917 Automobile Systems
++++++++++++++++ 1918 ++++++++++++++++
Delco Circuit Diagrams of the 1918 Automobile Systems
1918 -19 Delco Pierce Parts Catalog - Hudson
++++++++++++++++ 1919 ++++++++++++++++
Delco Circuit Diagrams of the 1919 1920 Automobile Systems
1919 Essex Model A Instruction Book
++++++++++++++++ 1920 ++++++++++++++++
1920's Hudson-Essex Service Station Tools and Shop Equipment This is really neat, being an old mechanic.
1920 Hudson Model 10-O to 12-O Parts List
++++++++++++++++ 1921 ++++++++++++++++
1921 Hudson Super Six Service Manual
++++++++++++++++ 1922 ++++++++++++++++
1922-27 Hudson Essex Paint Specifications REF SHEET No.36 July 1927
++++++++++++++++ 1924 ++++++++++++++++
1924-26 Hudson Parts List S/N 500,000-750,000
1924-26 Hudson, 1924-28 Essex Carburetor Instructions
1924-27 Essex Parts List S/N 100,000-706,000 January 1928
++++++++++++++++ 1925 ++++++++++++++++
1925 Hudson Parts List (November)
1925 Hudson Instruction Book (September)
1925-1930 Essex Motor Tune-Up and Specifications Booklet
++++++++++++++++ 1926 ++++++++++++++++
1926 Hudson Instruction Book (September)
1926 Hudson Essex Service Manual w/27 Supplement. S/N 500,001up
1926 Mechanical, Electrical Specifications Hudson and Essex
1926 Hudson Sedan and Brougham - Biddle and Smart - Body Parts List
1926 Hudson Coach 4 page Sales Brochure
++++++++++++++++ 1927 ++++++++++++++++
1927 Hudson Mechanical Specifications S/N 750,000up
1927 Hudson Essex Service Information Hand Book
1927-8 Hudson Super Six Marvel Carbureter and Heat Control Booklet B
1927 Hudson Super-Six Parts List. July 1927 S/N 750,001up
1927 Essex Super-Six Instruction Book
1927 Essex Super-Six Parts List S/N 500,001-706,269
1927 Essex Mechanical Specifications S/N 500,001up
1927 Installation of Stewart Warner Vacuum Fuel System
++++++++++++++++ 1928 ++++++++++++++++
1928 Essex Super-Six Parts List MAY
1928 Essex Mechanical Specifications S/N 790,399up
1928 Hudson Super Six Parts List JUNE
1928 Hudson Mechanical Specifications S/N 790,399up
++++++++++++++++ 1929 ++++++++++++++++
1929 Dover Commercial Super Six Mechanical Specifications S/N 10,001up REF SHEET No.38
1929 Essex Super Six Parts List JULY
1929 Essex Mechanical Information Hand Book JANUARY
1929 Essex Super Six Marvel Carbureter Booklet 61
1929 Essex Mechanical Specifications S/N 928,658up REF SHEET No.34
1929 Hudson Technical Information Hand Book
1929 Hudson, Essex, Dover Paint Specifications MARCH
1929 Hudson, Essex, Dover Paint Specifications AUGUST
1929 Hudson Super-Six Instruction Book APRIL S/N 825407up
1929 Hudson Essex Super Six Condensed Parts Price List JANUARY
1929 Hudson Super Six Parts List JANUARY S/N 825407
1929 Hudson Super Six Mechanical Specifications S/N 825,407up REF SHEET No.35
1929 Hudson Super Six Marvel Carbureter Booklet VB
Stewart Vacuum Gasoline System Model 113
1929 all makes ElectroLock information
++++++++++++++++ 1930 ++++++++++++++++
1930-39 Hudson Master Chassis Group Parts Book
1930 Essex Auto-Lite Gen and Ign Specifications S/N 1,165,674up
1930 Essex 'The Challenger' Body Parts List S/N 1165674 up
1930 Essex 'The Challenger' Parts List S/N 1165674 up
1930 Essex Super Six Technical Information and Specifications
1930 Essex Super Six Mechanical Specifications revised February
1930 Hudson Great 8 Electrical and Tune Up Specifications S/N 893,402up
1930 Hudson Super Eight Mechanical Specifications REF SHEET No.35
1930 Hudson 'Great Eight' and Essex 'The Challenger' Trimming Specifications REF SHEET No.42
1930 Essex Super Six Instruction Book S/N 116567up
++++++++++++++++ 1931 ++++++++++++++++
1931 Essex Super Six Mechanical Specifications REF SHEET No.34
1931 Essex Commercial Chassis Mechanical Specifications REF SHEET No.45
1931 Hudson Great Eight Mechanical Specifications REF SHEET No.35
1931 Paint Specifications Covering Greater Hudson Eight, Essex Super-Six REF SHEET No.36
1931 The Greater Hudson 8 Color Catalog
1931 Hudson 8 Instruction Book
1931 Hudson 8 Auto Lite Electric Instructions
++++++++++++++++ 1932 ++++++++++++++++
1932 Mechanical Specifications for the Greater Hudson Eight
1932 Essex Super-Six Technical Information
1932 Essex Terraplane Parts List
1932 Essex Mechanical Specs for the Greater Essex Super Six
1932 Essex Parts List for the New and Greater Essex Super Six. March
1932 Essex Super-Six Owners Manual
1932 Essex Body Parts List for the New and Greater Essex Super Six.
1932 Essex Terraplane Service Information and Adjustments s/n 350,000
++++++++++++++++ 1933 ++++++++++++++++
1933 Essex, Terraplane KT 8 Tune Up Specifications
1933 Hudson, Essex, Terraplane Service Information and Adjustments REF SHEET No.48
1933 Hudson Super Six owners manual
1933 Essex, Terraplane Majestic Model 66 Radio Installation and Tech Manual
++++++++++++++++ 1934 ++++++++++++++++
1934 Carter Carburetor Terraplane
1934 Terraplane Technical Handbook
1934 Hudson Eight Tune-up and Electrical
1934 Terraplane K, KU, KS, Tune-up and Electrical
++++++++++++++++ 1935 ++++++++++++++++
1935 Bendix Automatic Clutch Control
1935 Hudson Eight Model HT, HU, HHU, HTL, HUL Mechanical Specifications
1935 Hudson Eight Series 54 HT, 55 HU, 56 HHU Tune-up Specifications
1935 Accessory and Parts Merchandising Bulletins
1935 Mechanical and Technical Bulletins
1935 Parts Prices and Parts Specifications
1935 Parts Prices and Parts Specifications (not same as above)
1935 Hudson and Terraplane Zenith Model 680 Radio Service Manual
1935 Accessory and Parts Merchandising Bulletins
1935 Hudson Six Model GH Big Six Tune-up and Electrical Specifications
1935 Hudson Terraplane Brakes REF SHEET No.5 (December 1934)
1935 Service Information and Adjustments
1935 Hudson - Terraplane Technical Information Handbook
1935-38 Hudson Electric Hand Transmission Control
1935 Terraplane Tune-Up Specifications
1935 thru 1942 Hudson and Terraplane Carburetor Tune-up Manual
++++++++++++++++ 1936 ++++++++++++++++
1936 Hudson RCA Radio Model H-6
1936 Hudson RCA Radio Model CB-6
1936 - 1947 General Technical Policies and Information Bulletins
1936 Hudson 63 Electrical and Tune-Up Specifications
1936 Service Information and Adjustments
1936 Terraplane Model 61, 62 Mechanical Specifications
How What Why About the 1936 Hudsons and Terraplanes
++++++++++++++++ 1937 ++++++++++++++++
1937 - 38 Hudson Six Model 73, 83 Tune-Up Specifications
1937 - 38 Hudson Eight Tune-Up Specifications
1937 Terraplane Mechanical and Tune-Up Specifications
1937 Hudson-Terraplane Group Chassis and Body Parts Book
1937 Hudson Salesman Booklet. How What and Why
1937 Terraplane Salesman Booklet
Mechanical Procedure Manual. 1936 - 38
1937 Hudson Radio RCA Model 67M Installation and Instructions
1937 and 1939 General Parts Policies and Information Bulletins
1937-39 General Accessory Parts Policies and Information Bulletins
37 Automatic Clutch switch disassembled.
Color Chart for 1937 Hudson's.
++++++++++++++++ 1938 ++++++++++++++++
1938 Hudson 112 Tune-Up Specifications
1938 Hudson Service Information and Adjustments
1938 Hudson and Terraplane Group Parts Book
1938 Terraplane Tune-Up Specifications
++++++++++++++++ 1939 ++++++++++++++++
1939 Hudson SA and DB 39 Radio Service Manual
++++++++++++++++ 1940 ++++++++++++++++
1940 Hudson Group Parts Book Six and Eight
1940-47 Mechanical Specs and Tune-Up Specs with Adjustments
1940 Hudson Radio Service Manual
++++++++++++++++ 1941 ++++++++++++++++
++++++++++++++++ 1942 ++++++++++++++++
++++++++++++++++ 1946 ++++++++++++++++
Hudson Newsletter. Graehl Motor Service, Missoula Montana - Vol.1 No.10, Feb 1946
1946 Car Distribution Department Bulletins
++++++++++++++++ 1947 ++++++++++++++++
1947 Car Distribution Department Bulletins
++++++++++++++++ 1948 ++++++++++++++++
1948 Car Distribution Department Bulletins
1948 - 1953 General Technical Policies and Information Bulletins
1948 - 1949 Parts Merchandising Bulletin
1948 - 1949 Group Parts Catalog 480, 490
SALES FACTS - Next 12 items
1948 (Mar) MI Tests The New Hudson
1949 (Feb) Hudson vs Oldsmobile 98
1949 (July) Hudson vs Chrysler Saratoga, New Yorker
1949 (July) Hudson vs Oldsmobile Engines
1949 (July) Hudson vs Studebaker Land Cruiser
1949 (June) Hudson vs Chrysler Royal Windsor
1949 (June) Hudson vs Dodge Coronet
1949 (March) Hudson vs Buick Roadmaster
1949 (March) Hudson vs Packard
1949 (Sept) Compare Hudson Features
1949 Super 6 and 8 Service Manual
1949 Service Merchandiser Index
1949 Review Manual. Hudson Sales Clinic #1. Sales Improvement Program
1949 Service Merchandiser volume 1 Number 1
1949 Service Merchandiser Volume 1 Number 2
1949 General Parts Policies and Information Bulletins
1949 Car Distribution Department Bulletins
++++++++++++++++ 1950 ++++++++++++++++
1950 Car Distribution Department Bulletins
1950 Hudson Mechanical Procedures Manual 500 Series
1950 - 1954 General Parts Policies and Information bulletins
1950 - 1956 Hudson Parts Merchandising Bulletins
++++++++++++++++ 1951 ++++++++++++++++
1951 Car Distribution Department Bulletins
++++++++++++++++ 1953 ++++++++++++++++
1953 Car Distribution Department Bulletins
++++++++++++++++ 1955 ++++++++++++++++
1955 Accessory Merchandising Bulletins
1955 AMC Hudson Bulletins Groups 1.0000 thru 13.000
++++++++++++++++ 1956 - 7 and Jet ++++++++++++++++
1956 AMC Hudson Bulletins Groups 1.0000 thru 13.000
1957 AMC Hudson Bulletins Groups 1.0000 thru 13.000
++++++++++++++++ Other Hudson General Info ++++++++++++++++
Electric - Fuel and Serial #'s - 1930 to 1939
Tech Info index for White Triangle News articles. c/o Vernon E. Holt
More instruction on installing on a 47 - 53 Chevrolet Pickup.
*+*+*+*+*+*+*+*+*+*+*+*+*+*+*+*+*+*+*+*+*+*+*+
Trouble Shooting the Hudson Tele-Flash Signals
The dash signal (idiot) lights consist of a Battery Charge Tell-tale and Oil Pressure Tell-tale on the instrument panel which are used instead of gauges to indicate when generator is charging battery and if oil pressure is satisfactory. They are regular lamp bulbs connected to the accessory terminal of the ignition switch (operative only with ignition switch turned 'on') and are controlled by the generator cutout relay and oil line check-valve as described below.
GENERATOR CHARGE TELL-TALE: - The
cutout relay is provided with an extra set of ground contacts above the armature
and the tell-tale lamp lead is connected to this contact "T" terminal
on the regulator case. The lamp circuit is completed to ground through these
contacts. See car wiring diagram or model page for complete wiring circuits.
Operation: - The ground
contacts are normally closed with the main contacts open and open when the main
contacts close. When the ignition is turned on, the tell-tale lamp lights and
remains lighted until the main contacts close and the generator begins to charge
the battery. The lamp should remain lighted after the car speed Is brought up
beyond the cut-in point (approximately 7 MPH).
Trouble Shooting: - If the
tell-tale lamp does not light when ignition is turned on, ground tell-tale lamp
lead "T": terminal on regulator to the engine ( not the "B'
terminal). If lamp does not light, check for burned out bulb or loose
connections (see car model page wiring diagram). If lamp lights (indicating
ground contacts open), main contacts are fused or armature spring is weak
broken. If tell-tale lamp does not go out at speeds above cut-in point, ground
contacts are not opening when main contacts close. Check generator performance
by connecting accurate test ammeter in charging line. If trouble in regulator,
car manufacturer recommends that a new or replacement regulator installed
(regulator case is sealed, do not break seal)
OIL PRESSURE TELL-TALE: - The oil line
check valve on the right side of the crankcase is provided with an insulated
terminal pin which is grounded by the check-valve plunger when no pressure
exists in the oil line. The pressure tell-tale lamp lead is connected to this
terminal. A small hole in the check-valve plunger and a by-pass In the body
allow the passage of sufficient oil so that the plunger alternately opens and
closes the circuit at idling speeds, causing the tell-tale lamp to flash.
Operation: - The plunger
rests normally against the pin when no pressure exists in the oil line so that
the tell-tale lamp will light when the ignition Is turned on. At idling speeds
the plunger alternately opens and closes the circuit so that tell-tale lamp
flashes.
At speeds above idling (approximately 7 M.P.H.), the oil pressure holds the
check-valve plunger off its seat so that the tell-tale lamp does not burn or
flash.
Trouble Shooting: - If the
tell-tale lamp does not light when the ignition is turned on, ground check-valve
terminal to engine. If lamp does not light, replace bulb. If lamp does light,
remove terminal pin and see that it is straight and clean. Take off plug on top
of check-valve housing, remove plunger and see that It is clean and moves freely
up and down. Examine spring above plunger. If tell-tale lamp does not flash at
Idling speeds, see that small hole in plunger is clean and open.
